$102,995.00
TYM’s flagship tractor combines sophisticated design, powerful performance, and premium features for operator convenience.
Cash Price $99,995 After Rebates Applied Or $102,995 with 3.99% for 84 Months (Price Does Not Include Taxes or Trades)
The T130 can perform high-intensity work reliably, powered by a Deutz Common Rail Engine and Bosch’s state-of-the-art electronic hydraulic control system. It is ideal for use in commercial-scale rice and crop farming and livestock management. Automatic PTO with rotation and elevation functions adapt to the height of attachments, keeping the tractor stable and enabling a smooth ride.
In addition, the basic specifications are differentiated by applying a backlit LED emblem and T-VISION LED headlamp for enhanced aesthetics. The cabin is fully equipped with TYM’s premium operator features; remote engine start with a smart key, a smartphone wireless charger, and a heated and cooled cup holder.
|
T130 |
|
|---|---|
|
ENGINE
|
|
| Engine manufacturer | Deutz TCD3.6L4-CFXT95U |
| Type | Turbo charger |
| Gross engine power | 127 hp | 95 kW |
| PTO power | 118 hp | 87 kW |
| Rated engine speed | 2200 rpm |
| No. of cylinders | 4 |
| Displacement | 221 cu. in. |
| Air cleaner | Dual Dry |
| Alternator | 12V, 120A |
| Fuel system | CRDI |
|
POWERTRAIN
|
|
| Transmission type | Power Shuttle / 6-Speed Shift APS |
| No. of speeds | F36 x R36 w/Creep |
| Max. traveling speed | 23.1 mph |
| Brakes | Wet, Multi-disc |
| Steering | Hydrostatic |
| Clutch | Wet, Multi-plate |
|
HYDRAULIC SYSTEM
|
|
| Pump type | Dual gear pump |
| Implement flow | 20.1 gpm |
| Steering flow | 9.1 gpm |
| Total flow | 29.2 gpm |
| Category, 3-point hitch | II |
| Hitch lift capacity | 8262 lb |
| Hitch lift capacity at 24 inches behind link ends | 8014 lb |
| Lift control type | Position/Draft |
| No. of standard remote valves | 6 |
|
PTO
|
|
| PTO type | Independent |
| PTO control | Electro-hydraulic |
| PTO rear | 540/540E/1000 (Reversible shaft) |
|
CAPACITIES
|
|
| Fuel tank | 50.2 gal |
| Coolant | 19.1 qt |
| Crankcase | 2.1 gal |
| Transmission/Hydraulics system | 26.9 gal |
| Front axle | 1.9 gal |
|
DIMENSIONS & WEIGHTS
|
|
| Overall length with 3-point hitch | 176.8 in. |
| Overall width | 92.9 in. |
| Wheelbase | 102 in. |
| Height to top of cabin | 115.7 in. |
| Min. ground clearance | 16.1 in. |
| Min. turn radius with brakes | 166.5 in. |
| Min. turn radius without brakes | 189 in. |
| Weight with cab | 10020 lb |
|
STANDARD TIRES
|
|
| Agricultural – Front | 380/85 R 28 |
| Agricultural – Rear | 460/85 R 38(18.4R38) |
| Equipment Sub Type | Utility Tractor |
|---|---|
| Equipment Type | Tractor |
| Equipment Year | 2024 |
| Make | TYM Tractors |
